Kemppi MinarcMig 220 Auto MIG Welder Package

Stock Code:
K61008220AU
Price:
$3,550.00 excl GST

Downloads

Description

The Kemppi MinarcMig 220 Auto features automatic and manual mode set-ups as well as an adaptive arc regulation system to ensure precise welding quality and accurate ignition. Simplify the welding process – just take MinarcMig, select the material type and the plate thickness, and start welding. It is compatible with various materials, including steel, stainless steel, aluminium, and CuSi brazing filler wires.

This little giant delivers portable MIG/MAG welding power, offering 220 amps at a 20% duty cycle from a 16A, 1-phase mains supply.

The ready-to-weld MinarcMig 220 Auto MIG/MAG welding machine comes with the new Flexlite GC MIG welding torch, which includes integrated cable bending support and an ergonomic gun handle.

MinarcMig Auto models ensure premium results, allowing you to celebrate your perfected welding skills wherever your work takes you.

Specifications:
Connection voltage 1~ 50/60 Hz: 240V
Welding range: 20A/15V | 220A/28V
Output 20% ED: 220 A
Output 60% ED: 160 A
Output 100% ED: 120 A
Open circuit voltage: 70-75V
Wire feed mechanism: 2-roll, single-motor
Wire spool weight, max: 5kg
Wire spool diameter, max: 200mm
Mains fuse: 16A
Shielding gas pressure (max): 0.5 MPa
External dimensions L x W x H: 450 x 227 x 368mm
Weight (no accessories): 14.2kg
Degree of protection: IP23
Standards: IEC 60974-1, -5, -10, IEC 61000-3-12
EMC class: A
Operating temperature range: -20 to 40°C
Storage temperature range: -40 to 60°C

Details

  • Brand:
    Kemppi
  • Web Type:
    Kemppi Machines
  • Unit/Pack:
    EA
  • Pack Qty:
    1
